Actisense NMEA 2000 Micro, Front Panel Mount Wired Connector - Female A2K-PMW-F
Waterproof seals ensure the integrity of the NMEA 2000® connection and bulkhead/panel.
The female panel mount wired connector can easily replace any of the existing ‘drop’ glands on the Actisense QNB-1 to create a quick pluggable NMEA 2000® connection option.
Technical Specifications
| Electrical | |
| Rated Current | 4A |
| Rated Voltage
|
60VDC
|
| Mechanical | |
| Contacts | Brass, gold plated |
| Contact Carrier | Nylon & GF |
| Contact Polarization | Standard M12 -“A”- polarization |
| Mating Thread | M12 |
| Housing | Brass, nickel plated |
| Mounting Thread | PG9 (see diagram) |
| Mounting Nut | Brass, nickel plated – PG9 |
| Mounting Hole Dimensions | 15.3 mm (diameter) |
| Wires | 18 AWG (stripped and tinned) |
| Wire Jacket | PVC |
| Weight
|
20g
|
| Approvals and Certifications | |
| Protection | IP67 (when mated) |
| Operating Temperature | -25°C to +90°C |
| Connector Specification | Meets IEC61076-2-101 |
| NMEA 2000 Approved | |
| RoHS Compliant | |
| UL Certified (E321413) | |
Brand: Actisense
Comm Method: NMEA 2000®
Connector: NMEA 2000 Female
Country of Origin: China
Exterior Color: Silver
